Hyundai has rolled out the biggest of its compact excavator fashions, the 9-ton HX90A.
The brand new type fills a transitional hole between the producer’s compact and full-size excavator vary. The compact tail swing design and growth swing serve as are perfect for paintings in slim city or residential spaces. The growth can also be offset left or proper inside of an working vary. A 65-horsepower Yanmar engine with auto-regeneration powers it.
A typical large-angled dozer blade or non-compulsory four-way attitude dozer blade supplies added versatility, potency and steadiness, the corporate says. A dual-locking fast coupler improves protection when the usage of quite a lot of attachments. Moreover, the four-way hydraulics permit customers to mount more than one attachments with out switching hydraulic strains.
Throughout the Cab
Hyundai says a trademark characteristic of the brand new type is the up to date all-weather metal cab, with extra space, a much broader field of regard and stepped forward operator convenience.
A tiltable left-side console lets in for more uncomplicated get right of entry to to the cab, whilst a security lock machine prevents an operator from exiting the cab whilst the hydraulic controls are reside. When the protection lever and left aspect console are located upright, hydraulic purposes are disengaged.
The 7-inch LCD touchscreen observe options button alternatives for auto idle shutdown mode, max energy mode and trip velocity. A safety characteristic prevents the gadget from beginning with out a password.
An non-compulsory full-color built-in rearview digicam, viewable throughout the observe, is to be had.
The cab additionally includes a heated suspension seat, adjustable armrests and pilot operated hand levers for controlling the dozer blade and observe extension.
Simplified Upkeep
The HX90A options covers and hoods that open totally and a centralized lubrication financial institution for simplified provider and upkeep. The fin design of the radiator and oil cooler reduces clogging for more uncomplicated cleanout and sturdiness.
The HX90A compact excavator is roofed via HD Hyundai’s three-year, 3,000-hour guaranty, plus a five-year, 10,000-hour structural guaranty and 5 years of Hello MATE telematics.
Fast Specifications
- Engine: Yanmar 4TNV98C-PHYB
- Internet Energy: 65 hp at 2,400 rpm
- Running Weight: 20,040 kilos
- Usual Bucket: 0.33 cu. yd.
- Go back and forth Velocity: 3.2 mph
- Max. Digging Intensity: 14 feet 1 in
- Max. Digging Succeed in: 24 feet 4 in
- Tail Swing Radius: 5 feet 3 in
- Bucket Breakout Pressure: 11,907 lbf
- Arm Crowd Pressure: 8,884 lbf
