Bobcat’s new E40 compact excavator comes with a regular lengthy arm and minimum tail swing.
Within the video above, senior product specialist Eric Dahl led us on a walkaround excursion of the E40 at International of Concrete previous this 12 months.
The E40 runs on a 40-horsepower, turbocharged Bobcat engine that doesn’t require a diesel particulate clear out to fulfill Tier 4 Ultimate emission requirements.
At lower than 10,000 kilos, the excavator is considered as a subsequent step up for contractors in a position to take on extra tough jobs.
It options lower than 2 inches of tailswing and just about 4,000 kilos of lifting capability.
Dig intensity is ready 11 ft. Max achieve at floor stage is just about 18 ft. Bucket digging drive is 7,284 pound-feet.
Bobcat additionally designed the swing body castings and cylinders to stick inside the tracks when offset digging. That permits operators to dig flush up in opposition to a disadvantage and notice their paintings, the corporate says.
Bobcat says the E40 ranks top-of-the-line in its magnificence for over-the-blade and over-the-side lifting capability, even with its minimum tailswing. The corporate additionally touts its prime slewing energy for backfilling trenches or slewing a loaded bucket uphill. Additionally aiding backfilling is the same old blade with a 25-degree attitude left or proper to direct spoils with out forming windrows on all sides of the blade.
Fast Specifications
- Running weight: 9,180 lbs.
- Engine: 40-hp Bobcat
- Max bucket dig drive: 7,284 lbf
- Max achieve @ floor stage: 215.2”
- Max dig intensity: 130.4”
- Max unload peak: 146.8”
